12
page 22) when requested to do so by the remote Model 1082 and Model
1082/144.
Note The Remote Digital Loopback (RDL) will not work for 144 kbps.
You must first set the units to 128 kbps or slower to use the RDL.
Configuring DIP switch S2
Use the eight DIP switches in S2 to enable 19.2 kbps or 144* kbps syn-
chronous operation and set the loopback modes. The following table
summarizes default positions of DIP switches S2-1 through S2-8.
Detailed descriptions of each switch follow the table.
S1-8 Setting
On Response to RDL Request Enabled
Off Response to RDL Request Disabled
* 144 kbps data rate is only available on the Model 1082/144.
19.2 kbps rate is available on all Model 1082 series modems
except
for the 1082/144.
Not Assigned
S2 Summary Table
Position Function Factory Default
S2-1 19.2 or 14 4* k bps Enable Off
S2-2 Front Panel Switch Disable Off
S2-3 Response to LAL from DTE Off
S2-4 Off
S2-5 Off
S2-6 On
S2-7 Off
S2-8 Off Not Assigned
Compatibility Mode
Response to RDL from DTE
Not Assigned
Enabled
Disabled
