KX-TDA 600
Ideal for up to 960* users
Trunk options: Analogue, ISDN2/30 & IP
As technology changes so does the
way businesses communicate with
their customers. The KX-TDA 600,
with a capacity of up to 960
extensions provides the ideal solution
to handle all your customers system
requirements whatever their size.
Similar to the KX-TDA 100/200,
this system utilises many of the
existing cards allowing for an easy
migration path.
KX-TDA 600 system capacity
KX-TDA 600
Basic system
2 shelf system
3 shelf system
4 shelf system
(max)
Extensions
Extension port
without DXDP
160
320
480
640
with DXDP
240
480
720
960
Single Line Telephone (SLT)
160
320
480
640
Digital Proprietary
Telephone (DPT)
type 1**
without DXDP
80
160
240
320
with DXDP
160
320
480
640
Digital Proprietary Telephone (DPT)
type 2 ***
128
256
384
512
Analogue Proprietary Telephone (APT)
80
160
240
320
Direct Station Select (DSS) console
16
32
48
64
Voice Processing System (VPS)
8
8
8
8
Trunks
Trunk port
160
320
480
640
ISDN trunk
150
300
450
600
Analogue trunk
160
320
480
640
IP Gateway
160
320
480
640
Wireless
Portable Station (PS)
without MEC
64
128
192
256
with MEC
128
256
384
512
Cell Station (CS)
32
64
96
128
Doorphone port
16
32
48
64
PC Console
8
8
8
8
PC Phone
128
128
128
128
KX-TDA 620 11 slots
expansion shelf
F
ree slot
F
ree slot
F
ree slot
F
ree slot
F
ree slot
F
ree slot
F
ree slot
F
ree slot
F
ree slot
F
ree slot
F
ree slot
Bus card
Extra system options available:
●
Voice mail
●
Call Management Software
●
Cordless Telephony (DECT)
●
Integrated Headsets
●
Computer Telephony Integration (CTI)
●
Remote Branches
●
Home Worker Solution
This hybrid IP-PBX offers the
ultimate solution for your
customers office by
synthesising voice and data to
give a low cost, intelligent
communications environment.
P
ower supply
1
2
3
4
5
6
7
8
9 10 11
KX-TDA 600 10 slots system
configuration Main Cabinet
F
ree slot
F
ree slot
F
ree slot
F
ree slot
F
ree slot
F
ree slot
F
ree slot
F
ree slot
F
ree slot
F
ree slot
Option card slot
MPR (CPU)
P
ower supply
1
2
3
4
5
6
7
8
9 10
USB port for CTI / Prog
Serial RS232 port for SMDR / Prog
14
Initial configuration
- 0 lines
- 0 extensions
Configuration guidelines
The system has a basic configuration of
1 cabinet = 160 extensions & 160 trunks
Options
●
Can support up to three 620
expansion shelves
System configuration
●
KX-TDA 600 main CCU:
10 slots + 1 Busmaster slot
●
KX-TDA 620 expansion shelf:
11 slots + 1 Busmaster slot
(no dedicated option slot)
Maximum configuration
Lines (4 cabinets)
640
Extensions (4 cabinets)
960*
DECT Cell stations per cabinet
32
Interface cards per cabinet
4
