RQT8327
10
STEP 1 Connection
If your television does not have Audio/Video terminals, RF Modulator is necessary
a Connection with a television (Ô page 8 , A)
b Connection with a television and a video cassette recorder (Ô page 8 , B)
c Connection with a television and a cable box or satellite receiver (Ô page 9, C)
d Connection with a television, a video cassette recorder and a cable box or satellite receiver (Ô page 9, D)
VHF/UHF
RF IN OUT
RF VIDEO
AUDIO
R L S-VIDEO
IN
RF
3
2
Television This unit’s rear panel
75 Ω coaxial cable
Red White Yellow Red White Yellow
75 Ω coaxial cable (Included)
RF Modulator
Audio/video cable (Included)
VHF/UHF
RF IN OUT
RF VIDEO
AUDIO
R L S-VIDEO
IN
RF
VHF/UHF RF IN
VHF/UHF
RF OUT
4
3
Television
Audio/video cable (Included)
This unit’s rear panel
75 Ω coaxial cable
Red White Yellow Red White Yellow
75 Ω coaxial cable
RF Modulator
Video cassette recorder
VHF/UHF
RF IN OUT
RF VIDEO
AUDIO
R L S-VIDEO
IN
RF
VIDEO
AUDIO
R L S-VIDEO
OUT
RF
5
4
Television
Audio/video cable (Included)
This unit’s rear panel
75 Ω coaxial cable
Red White Yellow Red White Yellow
75 Ω coaxial cable
RF Modulator
Cable box or Satellite receiver
