71
Jams
For fax advantage assistance, call 1-800-435-7329.
4 Remove the jammed recording paper.
Jammed recording paper
Ink film
“T” shaped gear
(blue)
5 Turn the “T” shaped gear (blue) in the
direction of the arrow.
● Make sure that the ink film is
wrapped around the blue core
at least once.
Slack Reverse
Tight
Correct Incorrect
Blue core
The ink film is not wrapped
around the blue core.
6 Close the back cover securely by pushing
down on the dotted area at both ends (
).
Close the front cover securely ( ). 2
1
Dotted
area
1
2
