Frame & casing parts assembly (1), Mpl-2 – Panasonic AG-DVC20P User Manual
Page 3
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
92
VEP06F13B
FRONT C.B.A.
1
1
VKF4043
EVR COVER
1
93
VEP06G03A
S/S POWER C.B.A.
1
2
VGQ6407
SHEET
1
94
VEP06G04A
EJECT C.B.A.
1
3
VGQ6037
BATTERY LOCK HOLDER
1
95
VXW0803
CAMERA LENS U
1
4
VGU8749
BATTERY LOCK BUTTON
1
5
VKF4041
USB COVER
1
6
VXY1891
MEHCA CHASSIS U
1
7
VMB3314
DOOR LOCK SPRING
1
B1
XQN2+BJ5FJK
SCREW
1
8
VEK0J12
BATTERY CATCHER U
1
B2
XTV26+8GFN
SCREW
1
9
VGQ7231
BATTERY HOLDER
1
B3
XQN16+B5FJK
SCREW
1
10
VYK1Q33
MECHA FRAME 1U
1
B4
XTV26+8GFN
SCREW
1
11
VYK1W15
SIDE CASE (L) 1U
1
B5-B7
XTB3+10GFJK
SCREW
3
12
VSC5754
L EARTH PLATE B
1
B8,B9
XQN16+B6FJK
SCREW
2
13
VGU8946
T/W BUTTON
1
B10-12
VHD1133
SCREW
3
14
VGQ6365
ZOOM LEVEL
1
B13
VHD1353
SCREW
1
15
VMS7039
ZOOM SHAFT
1
B14
XQN16+B3FN
SCREW
1
16
VGQ6281
GRIP SW BRACKET
1
B15-17
XQN2+BJ6FJK
SCREW
3
17
VGQ6278
ZOOM GEAR
1
B18,19
XQN16+BJ4FN
SCREW
2
18
VYK1W27
GRIP COVER (1) U
1
B20-22
XQN16+B2FN
SCREW
3
19
D2ZGAZZB0004 ZOOM VR
1
B24,25
XQN2+BJ6FJK
SCREW
2
20
XUC2FP
E-RING
1
B26,27
XQN16+B5FJK
SCREW
2
21
VMP8446
MECHA ATTACHMENT PLATE F
1
B28,29
XQN2+BJ5FN
SCREW
2
22
VEE1B79
ZOOM/PHOTO CABLE
1
B30,31
XQN2+B5FJK
SCREW
2
23
VMT1197
ZOOM PROTECT SHEET
1
B32
XQN2+BJ5FN
SCREW
1
24
VMP8447
MECHA ATTACHMENT PLATE R
1
B33
XQN2+BJ4FJK
SCREW
1
25
VMP8448
MECHA ATTACHMENT PLATE B
1
B34-37
XTV26+8GFN
SCREW
4
26
VGQ6071
OPERATION P.C.B. PLATE
1
B38
XQN2+BJ35FN
SCREW
1
27
VMP8449
CASSETTE COVER PLATE
1
B39,40
XTV26+8GFN
SCREW
2
28
VGL1153
VTR SELECT PANELIGHT
1
B41,42
XQN16+B2FJK
SCREW
2
29
VMC1271
S/S CLICK SPRING
1
B43
XTV3+8GFN
SCREW
1
30
VMP8333
FRONT CBA FIXATION ANGLE
1
B45
XTB3+8FFJK
SCREW
1
31
VFC3902
GRIP BELT U
1
B46,47
XTB3+10GFJK
SCREW
2
32
VMP8331
BELT FIX ANGLE
1
B49,50
XTB3+8FFJK
SCREW
2
33
VGQ4494
S/S LEVER
1
B51-53
XTB3+10GFJK
SCREW
3
34
VGQ4272
S/S BUTTON PIECE
1
B55,56
XYN3+F6FN
SCREW
2
35
VGU7577
S/S BUTTON
1
B57,58
XQN2+BJ4FN
SCREW
2
36
VWJ1790
SIDE (R) FPC
1
B59,60
XQN2+BJ5FN
SCREW
2
37
VSC5753
L EARTH PLATE A
1
B61,62
XTN26+6GFN
SCREW
2
38
VJF1514
RCA COVER
1
B63,64
XTB26+6GFJK
SCREW
2
39
L2BB00000003 DEW SENSOR
1
B65-67
XQN2+BJ4FJK
SCREW
3
40
VEE0U49
EJECT CABLE
1
B68,69
XTB26+6GFJK
SCREW
2
42
VMP8450
SHOULDER BELT PLATE (F)
1
B70-72
XTB3+10GFJK
SCREW
3
45
VMP8445
AV JACK ANGLE
1
B73,74
XYN3+K6FN
SCREW
2
46
VMP8368
DV TERMINAL ANGLE
1
B75,76
XTB26+6GFJK
SCREW
2
48
VGQ5990
BATTERY CASE COVER
1
B77
XQN2+BJ4FN
SCREW
1
49
VMP8330
WEIGHT ANGLE
1
B79-82
XQN2+BJ4FN
SCREW
4
50
VMD2796
TRIPOD FRAME
1
B83-87
XQN16+B2FN
SCREW
5
51
VMP8328
TRIPOD FRAME ANGLE
1
B88
XQN2+B2FN
SCREW
1
53
VKW2418
REMOTE CONTROL WINDOW
1
B89
XQN16+B2FN
SCREW
1
55
VYK1W25
CASSETTE COVER U
1
B92,93
XQN16+B3FN
SCREW
2
60
VXP2522
MF RING U
1
B97
XQN2+BJ5FN
SCREW
1
61
VFC4129
LENS HOOD U
1
B98,99
XTB3+8FFJK
SCREW
2
62
VYQ3508
ND FILTER CASE U
1
65
VYK1Q80
LENS FRAME U
1
W1
XUC15FP
E-RING
1
66
VMG1357
FOCUS RING
1
70
VWJ1752
JACK FPC
1
71
VWJ1753
R FPC
2
72
VWJ1785
EVR FPC
2
73
VEK0K08
LCD FPC
1
74
VEK0J34
EVF FPC (1)
1
76
VEE1B80
FRONT CABLE
1
78
VGQ3457
PROTECTION BARRIER
1
79
VWJ1789
LENS INT FPC
1
80
VWJ1791
SIDE (L) INT FPC
1
81
VWJ1792
REAR INT FPC
1
82
VEK0K07
CCD INT FPC
1
83
VWJ1785
EVR FPC
1
84
VWJ1753
R FPC
1
85
VEP03G83B
MAIN C.B.A.
1
86
VEP06G00B
MOTHER C.B.A.
1
87
VEP06G01A
EVR INT C.B.A.
1
88
VEP06G02A
EVR INT2 C.B.A.
1
89
VEP01970A
BATTERY INT C.B.A.
1
90
VEP04890A
AV JACK C.B.A.
1
91
VEP06G05A
ZOOM C.B.A.
1
FRAME & CASING PARTS ASSEMBLY (1)
MPL-2
