(Measured Height) [Length to be cut off]
( 81 1/4” (2,064 mm) - [ ] ) =
Sizing the
Sure View Screen
If the door opening is smaller than 36” (914 mm) wide and
81 1/4” (2,064 mm) high, the Sure View Screen must be cut.
(Measured Width) [Length to be cut off]
( 36” (914 mm) - [ ] ) =
Determine Length to be Cut
from Top and Bottom Rails
To determine the length to be cut from the Top and Bottom Rails,
use the following formula:
Determine Length to be Cut from
Screen Housing Assembly and Catch Frame
To determine the length to be cut from the Screen Housing
Assembly and Catch Frame, use the following formula:
7
H
W
H
W
