1. Insert the Catch Frame into the bottom of the Top Rail
End Cap. Ensure that the Top Rail End Cap fits tight to
the right side of the door frame. (D)
2. Using a level, adjust the Catch Frame along the
mounting surface of the door frame to ensure that it is
positioned plumb. It is important that the bottom of the
Catch Frame fits tight to the door sill. (E)
3. Attach the Catch Frame to the door frame using the
5/8” (16 mm) Pan Head Screws provided. (F)
Installing the
Catch Frame
13
Top Rail
Catch Frame
5/8” (16 mm)
Pan Head Screw
Catch
Frame
Top Rail
End Cap
Catch
Frame
Push
Inser
t
Push
D
E
F
