The Initial Setup menu 14
111
En
Manual CH Setting Next Screen Proceed to the next screen if you need to adjust any
of the settings made by auto tuning.
• Change channels using the
CH +/– buttons.
• To skip the displayed channel (because there is no
station assigned to that channel), change the
Skip
setting to On .
• To manually fine tune the channel, change the AFT
setting to Off then adjust the Level setting.
VCR Plus+ CH
Setting Guide channels are used by the VCR Plus+ system
so that the channel number specified in the VCR
Plus+ programming numbers can be guaranteed to
correspond to the correct station. Look in your TV
guide to see which channel numbers should be
assigned to which guide channels.
• Use the
/ buttons to change the guide channel
for setting.
• Use the
/ buttons to change the channel
number.
• Use the
PREV / NEXT button to display
the previous/next 10 guide channels.
• To return to the Initial Setup menu, press
ENTER .
Video In/Out
Component Video
Out Interlace • Select if your monitor/TV is not compatible with pro-
gressive-scan video.
Progressive Select if your monitor/TV is progressive-scan compat-
ible. Check the operating instructions that came with
your monitor/TV if you’re not sure.
Audio In
External Audio Stereo • Select if the audio from the currently selected exter-
nal input is standard stereo.
Dual Mono Select if each channel carries a separate soundtrack.
Dual Mono
Recording L • Select to record the left channel of an external dual
mono source when recording to DVD in Video mode,
to HDD with HDD Recording Format set to Video
Mode On, or in
LPCM mode.
R As above, but for right channel recording.
Setting Options Explanation
