107

MAINTENANCE

Track Maintenance

WARNING

Moving parts can cut and crush body parts. When performing the

checks and adjustments recommended on the following pages,

stay clear of all moving parts. Never perform track measurement

or adjustments with the engine running.

Track Tension

Track adjustment is critical for proper handling. Always maintain

correct tension and alignment.

Track Tension Data Chart

Suspension

Weight

Measurement

Location

Slack

Measurement

IQ

10 lbs. (4.54 kg)

16″ ahead of rear

idler shaft

3/8″ - 1/2″

(1 - 1.3 cm)

M-10

10 lbs. (4.54 kg)

16″ ahead of rear

idler shaft

7/8″ - 1 1/8″

(2.2 - 2.9 cm)

NOTE: Tension adjustments should be made only after the track is

warmed up and limber.

1. Turn the engine off.
2. Lift the rear of the machine and safely support it off the ground.
3. Place the recommended weight or downward pressure on the track

at the specified distance (see chart) ahead of the center of the rear

idler wheel.

NOTE: Measure at the point where the weight is hanging.
