Installing the Display | 9
Connect the Video and Power Cables
Turn your computer off. Leave the power cord plugged into
the grounded outlet. Use the Dome EX display with the power
adapter and video cable shipped.
For the Dome E2 display, the power adapter is the
Ault MW116KA1249F53.
For the Dome E3, Dome E3c, and Dome E5 displays, the power
adapter is Ault MW122RA1223F52 or Ault MW122KA1223F52.
To connect the cables
1 Plug one end of the DVI cable into the DVI port on the interface
plate. Secure the connection.
2 Plug the power cord into the power input port on the
interface plate.
3 Plug the other end of the DVI cable into the video port on
the installed display controller. (Connect the first display of
a two-headed system, or the only display of a one-headed system,
to the primary (DVI #1) port.) Secure the connection.
4 Plug the other end of the power cord into the power supply.
5 Plug the power supply cord into a grounded AC outlet.
Tips
• Multiple displays. Connect all displays to the video board before
you turn on the computer and install the driver.
• Access to ports. For displays mounted on a desk stand, rotate the
LCD panel from portrait to landscape for access to the ports.
• Threading cables. Thread the DVI cable and power cord through
the stand column. Make sure the cable and cord run through the
notches. To reattach the stand cover, align the hooks with the
slots on the stand. Press the cover into place. A click sound signals
a secure connection.
