8 | Dome EX Display
Install the Display Controller
Before you install the Dome DX2 or the AX5 display controller,
choose a well-ventilated location with an adequate amount of space.
Excessive heat cannot dissipate when display vents are blocked.
Make sure a grounded AC outlet is within easy reach.
Turn your computer off. Leave the power cord plugged into the
grounded outlet.
To install the display controller
1 Remove the blank bracket from an available PCI or PCI Express slot.
2 Insert the display controller into the slot, align the connector pins,
and press the board down until it is firmly seated. Secure the
mounting bracket.
Note
• Dome DX2. The top port of the board is the primary (DVI #1) port.
• AX5 board. The bottom port of the board is the primary (DVI #1)
port. Both DVI ports provide dual-link support. Dual-link
functionality is available on Dome E3 and Dome E3c displays.
