Philips Mini-ITX Mainboard EPIA-MII - Manual (Page 29)

Chapter 2
2-14
USB pin-header: USB3/4
The mainboard provides 1 USB pin-header connector, allowing up to 2
additional USB ports. Please plug the USB 2-port module onto this pin-
header.
Wake-on LAN: WOL
This connector allows you to connect a network card with the Wake-On
LAN function. The connector will power up the system when a signal is
received through the network card. Please note that the function of ACPI
WOL may be disabled when users unplug the power cord or turn off the
power button manually.
Pin Signal Pin Signal
1 VCC 2 VCC
3 USB2 - 4 USB 3 -
5 USB2 + 6 USB 3 +
7 GND 8 GND
9 NC 10 GND
CLE266
2 1
USB 3/4
9 10
WOL
CLE266
