Chapter 2
2-6
Connecting the Power Supply
The VIA EPIA-MII Mini-ITX Mainboard requires an ATX power supply to
be connected. Before inserting the power supply connector, always make
sure that all components are installed correctly to ensure that no damage will
be caused.
ATX 20-Pin Power Connector
To connect the ATX power supply, make sure the plugs of the power supply
are inserted in the proper orientation and the pins are correctly aligned.
Then, push down the power supply plug firmly into the connector.
Pin Signal
1 3.3V
2 3.3V
3 GND
4 5V
5 GND
6 5V
7 GND
8 PW_OK
9 5V_SB
10 12V
11 3.3V
12 -12V
13 GND
14 PS_ON
15 GND
16 GND
17 GND
18 NC
19 5V
20 5V
CLE266
1 10
20 11
