11
Getting Star
ted
RQT9048
STB (Set Top Box) IR Settings:
e
, r to select an item, then
STB (Set Top Box) Type
Select the service being used.
Brand Name
Select the set top box brand.
You can also use [u] or [i] to view other pages.
Max. CH digits
Select the maximum number of channel digits to be entered in your
set top box. [This must not be selected when “Converter Box” is
selected for “STB (Set Top Box) Type”.]
OK Key Operation
Select whether or not the selected channel is confirmed by
pressing [OK] in accordance with your set top box.
–
–
–
–
Please choose settings based on your
Set Top Box.
OK
STB (Set Top Box) IR Settings
ABC
3 Digit
Brand Name
Cable Box/DVR
STB (Set Top Box) Type
Max. CH digits
Off
OK Key Operation
Test
e, r to select “Test”, then
Confirmation screen appears.
–
8
The correct operation of the Set Top Box
Control cable is checked. Enter a channel
that can be received by your set top box.
w
, q to select a position in
which the channel is entered
and e, r to set the number, then
You can also use the numbered buttons.
–
Start Set Top Box Control testing.
Please input the channel number
for testing. Use either numbered
buttons or UP/DOWN Cursors.
OK
STB (Set Top Box) IR Settings
Channel :
STB Type: Cable Box/DVR
Brand Name: Panasonic
Max. CH digits: 3 Digit
OK Key Operation: On
IR Code:
○○
1
0
Number
0
--
9
Confirmation screen appears.
e
, r to select the item, then
Yes, try other channels
Even if this unit can select a channel
on the set top box, it is recommended to select “Yes, try other
channels” and verify whether or not other channels can be selected
and properly controlled (
➔ step 8).
Yes, complete setup
Exits the Set Top Box Control setting screen.
No, try another code
Select this option when there are channels that cannot be selected.
If channels cannot be selected as set,
then “Yes, start over again” or “No, exit” will
be displayed.
“Yes, start over again” : Returns to step 6.
Set the channels again.
“No, exit” : The set top box is not controlled
with this unit.
If any channel cannot be selected, then this unit cannot properly
control the set top box.
–
–
–
Completed testing the / IR codes.
STB (Set Top Box) IR Settings
Has the STB channel changed to the number you
selected? Please select from the following:
Note: “Yes, try other channels” is
recommended to try several channels.
Yes, try other channels
No, try another code
Yes, complete setup
IR Code :
Completed testing all of the %s codes.
Do you want to start over the test again?
No, exit
Yes, start over again
STB (Set Top Box) IR Settings
Continued on next page.
