23
APPENDIX B
MODEL 2158 SERIES FACTORY
REPLACEMENT PARTS AND ACCESSORIES
*Only required with optional UI power supply (08055DCUI)
Patton Model # Description
Base Models
2158/L Local CopperLink Ethernet Extender, no power
supply
2158/R Remote CopperLink Ethernet Extender, no power
supply
2158-2PK CopperLink Ethernet Extender Kit: includes one
local (L) and one remote (R) Model 2158, no power
supply
07M2158_2168-A User Manual
Power Supplies
08055DCUI
08055-120-5-1
100-240VAC (+5V reg. DC/2A) Universal Input
Adapter.
120 VAC (+5V reg. DC/1A) Input Adapter
12V-PSM 12 VDC Input Adapter
24V-PSM 24 VDC Input Adapter
48V-PSM 48 VDC Input Adapter
Power Cords*
0805US American Power Cord
0805EUR European Power Cord CEE 7
0805UK United Kingdom Power Cord
0805AUS Australian Power Cord
0805DEN Denmark Power Cord
0805FR France/Belgium Power Cord
0805IN India Power Cord
0805IS Israel Power Cord
0805JAP Japan Power Cord
0805SW Switzerland Power Cord
