46
You can connect an external monitor to the output connector of the unit, output clips to the external monitor
and play them back on the monitor.
Outputting images to an external monitor for playback
Setting the outputs
1
Hold down [POWER] for at least 2 seconds to turn the power on.
2
Press [MODE].
The thumbnail display off screen appears.
3
Press [MENU].
4
Using [STOP] and [PLAY], select “AV OUT SEUP” setting item, and press [STILL].
5
Using [STOP] and [PLAY], select item, and press [STILL].
6
Press [MENU] to end the procedure.
AG-HPG1 0
OUTPUT
CH 1 CH 2 AUDIO VIDEO
1394
HD/SD-SDI
COMPONENT OUT
HD/SD-SDI output
Video output/
component output
HD/SD-SDI OUT
connector
VIDEO OUT connector
AUDIO OUT CH1/
CH2 connectors
Component
signal output
connector (D4
connector)
This unit
External monitor
