Connections and Setup
11
Connecting Using a DVI-D to
HDMI Cable
Use a DVI to HDMI cable when connecting
HDMI video equipment such as DVD players
to the DVI terminal.
1
Connect a DVI-D to HDMI cable to
the projector.
• Secure the connectors by tightening
the thumbscrews.
2
Connect the above cable to the
video equipment.
Note
• Select the input signal type of the video
equipment.
Optional
accessory
DVI-D to HDMI
cable
S-V
IDEO
P
R/C
R
P
B/C
B
Y
PR/
CR
P
B/C
B
Y
RGB
-HD
DV
I-D
RS-2
32
AC11
0-24
0
AC
11
0-2
40
12V
UGG
ER
1
2V
TR
UG
G
COM
P1
COM
P2
RS
-2
32
PB/C
B
PB
/C
B
PR
/C
R
PR
/C
R
COMP2
COMP1
RG
B-HD
DVI-D
Y
Y
S-V
ID
EO
DVD player or
DTV* decoder
DVI-D to HDMI cable
(sold separately)
To HDMI output terminal
