Panasonic DIGA DMR-EZ48V - Manual (Page 71)

71
RQT9056
The COMPONENT VIDEO OUT terminals on this unit can be used for either interlace or progressive output ( 91)
to provide a purer picture than the S VIDEO OUT terminal.
Using Component Video Cables for Better Video (Component Video Cables not
included)
Notes
 Usually you can watch video from COMPONENT VIDEO input on TV. When you want to playback VHS while recording on DVD, switch to
input 1 on TV.
 If this unit confi gured as above is connected to an amplifi er, etc., then turn “HDMI Priority” in the Setup Menu to “Off” before connecting the
HDMI cable. ( 65)
AC IN
P R Y P B
R-AUDIO
VIDEO
VIDEO
R-AUDIO-L
-L
S VIDEO
A AU
COMPONENT VIDEO OUT DVD/VHS COMMON OUT
COMPONENT
VIDEO IN INPUT 1
AUDIO IN VIDEO
R-AUDIO-L VIDEO O
S VIDEO
DVD PRIORITY OUT
DVD/VHS COMMON OUT
VIDEO R-AUDIO-L
COMPONENT VIDEO OUT
P R Y P B
AUDIO IN VIDEO
IN R L
RF OUT
RF IN
Y P B P R
Component
video cables
(not included)
Rear of TV
Audio/video cable
(included)
Rear of this unit
Audio cable
(not included)
Red White
Red White
Red White Yellow
Red White Yellow
 Adjust settings in “Component Output Signal” ( 64).
