Panasonic DVCPRO AJ-D250P - Manual (Page 49)

49
[STX] CTP [ETX] [STX] CTP [ETX] Uses the TCG in the preset mode.
The TCG starts counting up in the REC RUN mode upon
completion of the settings.
This command is ignored while a search control command
is being processed, during recording and in the INSERT
mode.
[STX] CTR [ETX] [STX] CTR [ETX] Uses the TCG in the regeneration mode.
This command is ignored while a search control command
is being processed, during recording and in the INSERT
mode.
RS-232C
$ Counter control commands
Sends data of computer Return data from VTR Description of command
[STX] CTS:data [ETX]
Parameters
data = hhmmssff
hh = 00 23: Hours
mm = 00 59: Minutes
ss = 00 59: Seconds
ff = 00 29: Frames
[STX] CTS [ETX] Presets the TCG data.
The value will be corrected as follows if the non-drop frame
preset value has been set while the drop frame mode is
established.
00:01:00:00 00:00:59:28
00:01:00:01 00:00:59:29
Error code ER001 is returned from the VTR when the TCG
is used in the regeneration mode or external VITC mode.
This command is ignored while a search control command
is being processed.
[STX] CUS:data [ETX]
Parameters
data = U
7 U 6 U 5 U 4 U 7 U 3 U 2 U 1 U 0
The input user bit data is set in
ASCII code.
UB data: Binary 4BIT
a 8
ASCII code: 0 9, A F
[STX] CUS [ETX] Presets the user’s bit data in the TCG.
Error code ER001 is returned from the VTR when the TCG
is used in the regeneration mode or external VITC mode.
This command is ignored while a search control command
is being processed.
[STX] CVP:data [ETX]
Parameters
data = ppqq
pp = 10 20: Insertion line 1
qq = 10 20: Insertion line 2
pp ≠ qq
(the same value cannot be
designated for both pp and qq)
[STX] CVP [ETX] Specifies two lines where the external VITC signal is to be
inserted.
This command is ignored while a search control command
is being processed, during recording and in the INSERT
mode.
$ Display control commands
Sends data of computer Return data from VTR Description of command
[STX] DFC:m [ETX]
Parameters
m = C: CTL mode
T: TC mode
U: UB mode
R: REMAIN mode
[STX] DFC [ETX] Sets the display mode of the counter display and the
reference data for searching.
CTL data reference:
CTL mode
TC data reference:
TC mode, UB mode, REMAIN mode
This command is ignored while a search control command
is being processed.
