11
ON
POWER
OFF
DIGITAL VIDEO CASSETTE
EJECT
MENU
REMOTE LOCAL
AUDIO
REC LEVEL
CH 1
CH 2
INPUT SELECT
S-VIDEO
LINE OPTION
BEGIN END
AUDIO OUT
SELECT
CH 3
CH 4
MENU DATA DOWN UP MODE - + SET
REW STOP FF PLAY PAUSE/STILL REC
RESET COUNTER
REMOTE
Digital Video Cassette Recorder
Operation
Before proceeding to operate the unit, make sure that the unit has been connected properly.
1
Turn on the unit’s power.
2
Insert the cassette tape.
Insert it at the prescribed position without forcing it in any way.
3
Check that the STOP lamp is lighted.
When the tape is inserted, the cylinder starts rotating automatically, the tape is loaded,
and the STOP mode is established.
It is possible to change the mode when a tape is inserted using the settings in Item No.
104 “TAPE IN MOD” of the Setup menu. (See page 29)
Turning on the power/inserting a cassette
1 2
3
