—34—
C
CONTROL BOX ASSEMBLY
CW499520315G
CW499520315K
1
CONTROL BOX, SINGLE
CW4994R1606A
CW4994R1606A
2
CONTROL PANEL
CW3720R6163A
CW3720R6163A
3
ESCUTCHEON
CW383120060C
CW383120060C
4
CAPACITOR
CW6120R2194D
CW6120R2194P
R
5
POWER CORD ASS'Y
CW2H00677X
CW2H00677U
R
6
THERMISTOR
CW632320003D
CW632320003D
R
7
COVER
CW355130015A
CW355130015A
8
MAIN P.C.B ASS'Y
CW687110070T
CW687110070T
R
9
DISPLAY P.C.B ASS'Y
CW687120195T
CW687120195T
R
10
MOTOR ASS'Y, SYNC.
CW2H01102A
CW2H01102A
R
D
PIPE
1
TUBE ASSEMBLY, SUCTION INDOOR
CW521130250D
CW52110094B
2
TUBE ASSEMBLY, DISCHARGE SINGLE
CW521130066A
CW521130325D
3
TUBE, EVAPORATOR
CW521030144L
CW521030144U
4
TUBE, EVAPORATOR
CW521030144T
CW521030144V
5
TUBE ASSEMBLY, CONNECTOR
CW5211R7059V
CW521110067F
6
TUBE, CAPILLARY
CW521030646A
CW5425R3147X
PART NO.
DESCRIPTION
REMARK
CW-XC184HU
CW-XC244HU
LOCATION
NO
.
