—33—
A FRONT GRILLE ASS'Y CW353110189A CW353110189A
1 GRILLE, FRONT CW353010138A CW353010138A
2 INLET, GRILLE CW353010139A CW353010139A
3 AIR FILTER ASS'Y CW5231R6159F CW5231R6159F
4 HORIZONTAL, LOUVER CW4758R7264J CW4758R7264J
5 HORIZONTAL, LOUVER CW4758R7278J CW4758R7278J
B COMP&ACCESSORY ASS'Y
1 ANTI-VIBRATION BUSH CW4H00982C CW4022-L005A
2 COMPRESSOR CW2520MBK2KA CW2520HFK2CA R
3 GASKET CW4986-L001G CW4986-L004A
4 OVERLOAD PROTECTOR CW6750-L025A - R
5 TERMINAL, COVER CW3550-L004A CW3550-L005A
6 BASE PAN WELD ASS'Y CW304130016B CW304110010F
7 BARRIER, SINGLE CW479010036A CW479010036A
8 SCOLL CW307220009A CW307220009A
9 AIR GUIDE ASSEMBLY CW523920001V CW523920001V
10 CABINET ASS'Y CW3091R6057P CW3091R6056J
11 DAMPER, VENTILATION CW4900R7265A CW4900R7265A
12 MOUNT, MOTOR CW4960R2895B CW4960R2895B
13 MOTOR ASSEMBLY, SINGLE CW468120011J CW468120011L R
14 SHROUD CW4998R1597A CW4998R1602A
15 FAN , TURBO CW590120009A CW590120009A R
16 FAN , AXIAL CW590120010A CW5900R1330B R
17 CLAMP, SPRING CW3H02932C CW3H02932C
18 ORIFICE CW494820014A CW494820014A
19 BRACE CW4800R7272A CW4800R7271A
20 EVAPORATOR ASSEMBLY, FIRST CW542120017N CW542120017N
21 CONDENSER ASSEMBLY, BENT CW540320062B CW540320032F
22 VERTICAL, LOUVER CW4758R6157A CW4758R6157A
23 REMOTE CONTROLLER ASSEMBLY CW671190018A CW671190018A R
24 OPERATING INSTRUCTION CW382820391D CW382820391D
25 INSTALLATION KIT CW312710015U CW312710015U R
26 UPPER GUIDE CW2H00858D CW2H00858D
7. REPLACEMENT PARTS LIST
R : Recommendable parts.
PART NO.
DESCRIPTION REMARK
CW-XC184HU CW-XC244HU
LOCATION
NO .
