1.1 SAFETY PRECAUTIONS
1. When servicing, set the POWER of CONTROL BOARD
to Off and unplug the power cord.
2. Observe the original lead dress.
If a short circuit is found, replace all parts which have
been overheated or damaged by the short circuit.
3. After servicing, make an insulation resistance test to
prevent the customer's exposure to shock hazards.
1.2 INSULATION RESISTANCE TEST
1. Unplug the power cord and connect a jumper between
2 pins (black and white).
2. The grounding conductor (green or green and yellow) is
to be open.
3. Measure the resistance value with an ohm meter between
the jumpered lead and each exposed metallic part on the
equipment.
4. The value should be over 1 M
Ω
.
1. PREFACE
This service manual provides various service information, including the mechanical and electrical parts, etc.
This room air conditioner was manufactured and assembled under a strict quality control system.
The refrigerant is charged at the factory. Be sure to read the safety precautions prior to servicing the unit.
1.3 SPECIFICATIONS
* DB:Dry Bulb ** WB:Wet Bulb
NOTE : Specifications are subject to minor change without notice for further improvement.
CW-XC184HU CW-XC244HU
POWER SUPPLY Ø, V, Hz
COOLING CAPACITY Btu/h.
POWER INPUT W
RUNNING CURRENT A
EER Btu/h.W
REFREIGERANT (R-22) CHARGE
OPERATING INDOOR °F(°C)
TEMPERATURE OUTDOOR °F(°C)
EVAPORATOR
CONDENSER
FAN
INDOOR
OUTDOOR
FAN SPEED FAN/COOLING
FAN MOTOR
OPERATION CONTROL
ROOM TEMP. CONTROL
AIR DIRECTION VERTICAL
CONTROL HORIZONTAL
CONSTRUCTION
PROTECTOR
COMPRESSOR
FAN MOTOR
POWER CORD
DRAIN SYSTEM
NET WEIGHT lbs(kg)
DIMENSION(W*H*D) inch(mm)
1, 208/230, 60
17,800/17,300 23,500/23,000
1,660/1,620 2,500/2,450
7.4/7.9 11.2/12.0
10.7/10.7 9.4/9.4
780g (27.5 oz) 980g (34.6oz)
DB : 80(26.7) WB : 67(19.4)
DB : 95(35) WB : 75(23.9)
3 ROW 15 STACKS, SLIT-FIN TYPE
2 ROW 19 STACKS, LOUVERED-FIN TYPE
TURBO FAN
PROPELLER TYPE FAN WITH SLINGER-RING
3/3
6 POLES
REMOTE CONTROL
THERMISTOR
MANUAL
AUTO
SLIDE IN-OUT CHASSIS
INTERNAL OVERLOAD PROTECTOR
INTERNAL THERMAL PROTECTOR
1.6m(63") (3WIRE WITH GROUNDING)
ATTACHMENT PLUG(CORD-CONNECTED TYPE)
DRAIN PIPE OR SPLASHED BY FAN SLINGER
123(55) 146(66)
26 * 16 27 /
32
* 26 17 /
32
(660 * 428 * 675) 26 * 16 27 /
32
* 30 17 /
32
(660 * 428 * 770)
MODELS
ITEMS
