PRT-6

Ref. No.

Part No.

Part Name & Description Pcs

Remarks

Ref. No.

Part No.

Part Name & Description Pcs

Remarks

ELECTRICAL REPLACEMENT PARTS LIST

E1

VEAB0317A

REAR P.C.BOARD

1 (RTL)

E2

VEAB0318A

PANEL P.C.BOARD

1 (RTL)

E1

VEAB0317A

REAR P.C.BOARD

1 (RTL)

B100

CR2032L/B

BATTERY

1

C1

F2D1D1010001

E.CAPACITOR CH 20V 100U

1

C2

F2D1D1010001

E.CAPACITOR CH 20V 100U

1

C4

F1H1H511A650

C.CAPACITOR CH 50V 510P

1

C6

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C7

F3H1V156A037

T.CAPACITOR CH 35V 15U

1

C9

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C10

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C12

F1H1H4730002

C.CAPACITOR CH 50V 0.047U

1

C14

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C15

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C18

F1H1H222A789

C.CAPACITOR CH 50V 2200P

1

C19

EEFUD0J101ER E.CAPACITOR CH 6.3V 100U

1

C21

F2G1A471A026

E.CAPACITOR CH 10V 470U

1

C23

F2G1A471A026

E.CAPACITOR CH 10V 470U

1

C24

F1H1H511A650

C.CAPACITOR CH 50V 510P

1

C100

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C101

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C102

F3F1C475A037

T.CAPACITOR CH 16V 4.7U

1

C103

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C103

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C104

F1H1H220A650

C.CAPACITOR CH 50V 22P

1

C105

F1H1H220A650

C.CAPACITOR CH 50V 22P

1

C106

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C107

F3G1A476A029

T.CAPACITOR CH 10V 47U

1

C108

F3G1A476A029

T.CAPACITOR CH 10V 47U

1

C109

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C111

F3G1A476A029

T.CAPACITOR CH 10V 47U

1

C112

F1H1A105A019

C.CAPACITOR CH 10V 1U

1

C113

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C114

F1H1A105A019

C.CAPACITOR CH 10V 1U

1

C115

F1H1A105A019

C.CAPACITOR CH 10V 1U

1

C116

F1H1A105A019

C.CAPACITOR CH 10V 1U

1

C117

F1H1H223A789

C.CAPACITOR CH 50V 0.022U

1

C118

F1H1A105A019

C.CAPACITOR CH 10V 1U

1

C119

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C120

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C121

F1H1H103A789

C.CAPACITOR CH 50V 0.01U

1

C122

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C123

F1H1A105A019

C.CAPACITOR CH 10V 1U

1

C124

F1H1A105A019

C.CAPACITOR CH 10V 1U

1

C125

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C126

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C127

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C128

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C129

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C200

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C201

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C202

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C203

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C204

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C205

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C206

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C207

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C208

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C209

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C210

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C211

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C213

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C217

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C219

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C220

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C221

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C222

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C223

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C224

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C225

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C226

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C227

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C228

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C229

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C230

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C231

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C232

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C233

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C234

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C235

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C236

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C237

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C238

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C239

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C240

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C241

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C242

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C300

F1H1H102A793

C.CAPACITOR CH 50V 1000P

1

C301

F1H1H102A793

C.CAPACITOR CH 50V 1000P

1

C302

F1H1H102A793

C.CAPACITOR CH 50V 1000P

1

C303

F1H1A105A019

C.CAPACITOR CH 10V 1U

1

C304

F1H1A105A019

C.CAPACITOR CH 10V 1U

1

C400

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C401

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C402

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C403

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C406

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C407

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C408

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C409

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C411

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C412

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C413

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C415

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C416

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C417

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C419

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

C420

F3H1V156A037

T.CAPACITOR CH 35V 15U

1

C421

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C422

F1H1H102A793

C.CAPACITOR CH 50V 1000P

1

C423

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C424

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C425

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C426

F3F1V105A028

T.CAPACITOR CH 35V 1U

1

C427

F3F1C106A039

T.CAPACITOR CH 16V 10U

1

C428

F1L1C2260007

C.CAPACITOR CH 16V 22U

1

C429

F1L1C2260007

C.CAPACITOR CH 16V 22U

1

C430

F1H1H101A650

C.CAPACITOR CH 50V 100P

1

C431

F1H1E1040006

C.CAPACITOR CH 25V 0.1U

1

D1

MAZ30620ML

DIODE

1

D3

B0JCME000014

DIODE

1

D4

B0JCME000014

DIODE

1

D100

MA3J142K0L

DIODE

1

D101

MA3J142K0L

DIODE

1

D102

MA3J142K0L

DIODE

1

D300

MA3J143A0L

DIODE

1

D301

MA3J143A0L

DIODE

1

D302

MA3J143A0L

DIODE

1

F1

K5H162300003

FUSE

1

F3

K5H102300011

FUSE

1

F4

K5H501300008

FUSE

1

F5

K5H501300008

FUSE

1

F6

K5H501300008

FUSE

1

F7

K5H102300011

FUSE

1

F8

K5H501300008

FUSE

1

FL1

F1Z1H4720003

FILTER

1

FL2

F1Z1H4720003

FILTER

1

FL3

F1Z1H4720003

FILTER

1
