Placement Guide
• Use this information as a guide to find out about the screen size when the projector is placed at a certain location, or
to find out the approximate size of a screen that will be required.
• The projection distance over which focussing is adjustable is 1.20 m (3.9 feet) to 11.02 m (36.15 feet). The projector
should be placed within this range.
• When suspending the projector from the ceiling, change the projection method. See “Vertical Flip / Horizontal Flip” on
E-50.
* There is a tolerance of ±5% due to design values.
* This table uses the lens apex and lens center as references and requires that the projector be in a horizontal condition
(with front and rear adjusters fully withdrawn).
34"
40"
60"
80"
100"
120"
150"
200"
250"
300"
0.69 ן0.52
0.81
ן0.61
1.21
ן0.91
1.62
ן1.21
2.03 ן1.52
2.43 ן1.82
3.04 ן2.28
4.06
ן3.04
5.08
ן3.81
6.09 ן4.57
— – 1.20
1.22 – 1.44
1.85 – 2.17
2.51 – 2.91
3.14 – 3.65
3.77 – 4.39
4.72 – 5.49
6.30 – 7.34
7.89 – 9.18
9.47 – 11.02
0.48
0.72
1.07
1.43
1.79
2.14
2.68
3.58
4.48
5.38
0.07
0.11
0.16
0.22
0.27
0.32
0.40
0.54
0.67
0.81
Screen Size
Designation (Inches)
Screen Size Width x Height Projection Distance Height h1 Height h2
2.27 ן 1.70
2.65
ן 2.00
3.96
ן 2.98
5.31 ן 3.96
6.66 ן 4.98
7.97 ן 5.97
9.97
ן 7.48
13.32
ן 9.97
16.66 ן12.50
19.98 ן14.99
(m) (feet)
— – 3.94
4.00 – 4.72
6.07 – 7.12
8.23 – 9.55
10.30 – 11.98
12.37 – 14.40
15.49 – 18.01
20.67 – 24.08
25.89 – 30.12
31.07 – 36.15
1.57
2.36
3.51
4.69
5.87
7.02
8.79
11.75
14.70
17.65
0.23
0.36
0.52
0.72
0.89
1.05
1.31
1.77
2.20
2.66
(m) (feet) (m) (feet) (m) (feet)
Wide – Tele Wide – Tele
Screen Size and Projection Distance
Unit: m (feet)
250"
200"
150"
120"
100"
80"
60"
1.85–2.17
(6.07–7.12)
2.51–2.91(8.23–9.55)
3.14–3.65(10.30–11.98) 3.77–4.39(12.37–14.40) 4.72–5.49(15.49–18.01)
6.30–7.34(20.67–24.08)
9.47–11.02(31.07–36.15)
7.89–9.18(25.89–30.12)
1.22–1.44
(4.00–4.72)
h1
h2
300"
40"
34"
1.20
(3.94)
Height from center of
lens to bottom edge
of the projection
Height from center of
lens to top edge of
the projection
Lens surface
of the main
unit
Screen Size Designation (Inches)
Width
Height Screen size (Diagonal)
