Preparing the Remote Control
Inserting the Batteries
When using the remote control for the first time, install the batteries that were supplied.
CAUTION
When replacing batteries, purchase two of the same type of AAA battery.
Heed the regulations in effect in your region on the disposal of spent batteries.
Remote Control Range
Point the infrared transmitter of the remote control toward the remote control sensor located at the front or rear of the main unit
and operate.
Reception of the remote control signal should generally be possible within the range illustrated below.
Side View Top View
Note
* Exposure of the main unit’s remote control sensor or the remote control infrared transmitter to bright light or the obstruction of the signal
by an obstacle located in the pathway may prevent operation.
* The remote control will not function when the battery is exhausted.
(B)
(C) (A)
2 Insert the batteries to match
the “+” and “–” as indicated in-
side the compartment. 1 Slide the battery compartment
cover (located on the bottom
of the remote control) and pull
off. 3 (A) Leaving a little space in the front, close
the lid, (B) then with the back pressed tightly,
(C) press the lid towards the front.
MENU PRESS TO OPEN
PRESS TO OPEN
SOURCE
STANDBY
STATUS
AUTO QUICK MENU
40 °
20 °
5m / 16.4 feet
5m / 16.4 feet
7m / 16.4 feet
7m / 16.4 feet
40 °
30 °
50 °
10 °
40 °
40 °
Remote control
infrared transmitter
Remote control
infrared transmitter
Remote control
sensor
Remote control
sensor
