14
VQT2Z95
∫ To return the USB terminal slide lever to its original position
While holding down the USB terminal
slide lever, slide it to its original
position and close the USB terminal
cover.
≥ Please refer to page 60 if the status indicator flashes quickly.
≥ During the charging,the unit can not be turned on with the power
button. In order to turn on the unit, disconnect it from the PC.
≥ We recommend using Panasonic batteries ( l 8, 71).
≥ If you use other batteries, we cannot guarantee the quality of this product.
≥ Do not heat or expose to flame.
≥ Do not leave the battery(ies) in an automobile exposed to direct
sunlight for a long period of time with doors and windows closed.
∫ Charging/Recording time
≥ Temperature: 25 oC (77 oF)/humidity: 60%RH
* Maximum continuous recordable time for one scene:
j If [REC MODE] is set to / / :
29 min 59 sec
j If [REC MODE] is set to :
Approx. 20 min (up to 4 GB recording capacity)
≥ These times are approximations.
≥ The indicated charging time is for when the battery has been
discharged completely. Charging time and recordable time vary
depending on the usage conditions such as high/low temperature.
Charging and recording time
Battery model
number
[Voltage/
Capacity
(minimum)]
Charging
time
Recording
mode
Maximum
continuous
recordable
time
*
Actual
recordable
time
Supplied battery/
VW-VBJ10
(optional)
[3.6 V/940 mAh]
4 h 10 min
1 h 20 min 45 min
/ 1 h 35 min 50 min
1 h 50 min 1 h



