PATTON ELECTRONICS MODEL 1094A
INTERFACE PIN ASSIGNMENTS
(Continued)
V.35 Interface
(M/34F Female Connector)
(DCE Configuration)
Pin #
Signal
B ...........................SGND
(Signal Ground)
C ...........................RTS
(Request to Send)
D ...........................CTS
(Clear to Send)
E ...........................DSR
(Data Set Ready)
F............................CD
(Carrier Detect)
H ...........................DTR
(Data Terminal Ready)
L............................LLB
(Local Line Loop)
M ...........................TM
(Test Mode)
N ...........................RDL
(Remote Digital Loop)
P ...........................TD
(Transmit Data)
R ...........................RD
(Receive Data)
S ...........................TD/
(Transmit Data-B)
T............................RD/
(Receive Data-B)
U ...........................XTC
(External Transmit Clock)
V ...........................RC
(Receive Timing)
W ...........................XTC/
(External Transmit Clock)
X ...........................RC/
(Receive Timing)
Y ...........................TC
(Transmit Clock-A)
AA ..........................TC/
(Transmit Clock-B)
A
AP
PP
PE
EN
ND
DIIX
X C
C
PATTON ELECTRONICS MODEL 1094A
INTERFACE PIN ASSIGNMENTS
(Continued)
X.21 Interface
(DB-15 Female Connector)
(DTE /DCE Configuration)
Pin #
Signal
1 ...................... Frame Ground
2 ...................... T (Transmit Data-A)
3 ...................... C (Control-A)
4 ...................... R (Receive Data-A)
5 ...................... I (Indication-A)
6 ...................... S (Signal Element Timing-A)
7 ...................... BT (Byte Timing-A)
8 ...................... SGND (Signal Ground)
9 ...................... T/ (Transmit Data-B)
10 ...................... C/ (Control-B)
11 ...................... R/ (Receive Data-B)
12 ...................... I/ (Indication-B)
13 ...................... S/ (Signal Element Timing-B)
14 ...................... BT/ (Byte Timing-B)
