MP3/Windows Media TM Audio/JPEG Playback 51
The DVD/VCR will play MP3, Windows Media TM Audio and JPEG files
that you record and finalize on a CD-R (Compact Disc-Recordable)
or CD-RW (Compact Disc-Rewritable).
These discs may contain pictures in a JPEG format or audio tracks in
an MP3 or Windows Media
TM Audio format. For example, you may have
photographic film developed by a retailer that places the pictures on a
CD-R for you. These pictures may be in JPEG format. Or, you may copy
or download MP3/Windows Media
TM Audio music files from certain
legal Internet sites, then copy those files onto a CD-R or CD-RW.
You cannot make or record such discs using this DVD/VCR. See your
computer manual for details on recording.
Keep these characteristics in mind when making discs you intend to
play on the DVD player of this DVD/VCR.
● Record MP3 files at a sampling frequency of 44. 1 kHz or
48 kHz. Record in a constant bit rate between 32 kbps and 320
kbps.
● Record Windows Media TM Audio tracks at a sampling frequency of
44. 1kHz or 48kHz. Record in a constant bit rate between 48 kbps
and 192kbps.
● When recording JPEG files, the size of the picture should be
between 32 x 32 and 6300 x 5
100 dots.
1 Press DVD to put the DVD/VCR in DVD mode.
DVD light will appear on the front of the DVD/VCR.
2 When you put a CD-R or CD-RW with MP3,
Windows Media
TM Audio or JPEG files in the DVD/VCR, a File
List will appear automatically. Or if the disc is already in the
DVD/VCR and you want to call up the file list, press
DISC/VCR MENU. (If you use PLAY B to close the disc tray,
Playback starts automatically.) Press K or L to select a
folder, MP3,Windows Media
TM Audio or JPEG file.
3 If you choose a track or file, press PLAY B or OK.
Starting with the track or file you selected, the tracks/files will
play in the order they were recorded, i.e.
1, 2, 3.
If you select a folder and press OK, the tracks or files
within that folder will appear. Press K or L to select
the track or file you want to play, then press PLAY B
or OK.
● Press TITLE to return to the first item in the highest level of
folders or files. You also can press
{ or B to return to
previous or next levels.
● To change the Transition Mode for JPEG playback, press
MODE repeatedly until Transition Mode appears on top of
the TV screen during playback.Then press
{ , B or OK to
switch CUT IN/OUT and FADE IN/OUT. If you choose
CUT IN/OUT, the images will cut in and out sharply as
playback progresses. If you choose FADE IN/OUT, the
images will fade in and out as playback progresses.
● To change the size of the playback image, press MODE
repeatedly until SIZE MODE appears at the top of the TV
screen during playback. Then press
{ , B or OK to switch
NORMAL( 100%) and SMALL(95%).
● Press MODE or BACK to remove the display.
● During JPEG playback, press ANGLE to rotate a picture 90
degrees clockwise.
4 To stop playback, press STOP C.
• MP3/Windows Media TM Audio
tracks and JPEG images are
known as files. Groups of files
are called folders.
• Folders have the icon, MP3
files have the icon,Windows
Media TM Audio files have the
icon and JPEG files have the
icon.
• A maximum of 255 folders can
be recognized. A maximum of
999 files can be recognized.
• If you use PLAY B to close the
disc tray, playback starts
automatically. If you use
OPEN/CLOSE A to close the
disc tray, you have to press
PLAY B to start playback.
• During playback, use the
Number buttons or NEXT
∑
and PREV
w to change tracks.
If a track is not available, “X”
will appear on the TV screen,
and playback may resume at an
incorrect track or may continue
with its current track.
• To see the File List during
playback, press DISC/VCR
MENU. The current track will
be highlighted.
• Progressive JPEGs (JPEG files
saved in the progressive format)
will not play on this DVD player.
• Copyright protected
Windows Media TM Audio files
will not play on this DVD player.
• High resolution JPEG files takes
longer to be displayed.
• SIZE MODE may have no effect
on some files (e.g. files with a
small picture size).
2-3
4
Helpful Hints
1
