11
Installation
Notes:
•
Similar connections are available at the INPUT 1, 2, 3, 4 input terminals.
Input 4 is located on the front of the unit.
Select the desired VIDEO input position by pushing the TV/VIDEO button. (See page 33)
•
When connecting video cables, priority is given to the S-Video cable when the S-Video input terminal and the video input
terminal are connected at the same time.
How to connect the “1, 2, 3, 4” Input Terminals
Connects VCRs and other peripheral equipment
TO
AUDIO
AMP
L
R
AUDIO
VIDEO
S-VIDEO
L
R
INPUT
PROG
OUT
2 1 3
(Super-VHS VCR)
Audio
OUT
Video
OUT
S-Video
OUT
R L
VIDEO
AUDIO
TO
AUDIO
AMP
L
R
AUDIO
VIDEO
S-VIDEO
L
R
INPUT
PROG
OUT
2 1 3
(VHS VCR)
VIDEO
AUDIO
Audio
OUT
Video
OUT
R L
Similar connections are available at the INPUT 1, 2, 4 input terminals.
Similar connections are available at the INPUT 1, 2, 3, 4 input terminals.
