19
Figure 3-11: The Stack member list Web page
!
NOTE
Please note when choose “Master” from “Stacking State”. It allows user to assign this
Switch as Master device in this stack group. Then the rest of the Switches should be slave
device.
!
NOTE
Slave switch IP will be covered by Master one, and disappear temporarily. The slave IP
address can be the same as Master IP address. Thus, if master switch is malfunction, you
can still access the other switch by same IP address.
!
NOTE
If you have difficulty on selecting another switch, you may be connecting to the slave
switch
’s web, please close the browser window, use the “arp –d * ” DOS command to clear
the ARP table and then reopen the web.
You can key in Master IP (ex: 192.168.100.128), and choose “Stack Config”, and then the entire stack
member list will be displayed in Stack Member List. You can then choose the switch you want to con-
figure from list of
“Stack Access” bar. The screen in Figure 3-12 appears.
