Connection with existing systems
This is an example where the connections for the existing system and the 2K system are switched within the router.
To switch to the 2K system mode, select “2048 (PsF)” or “1920 (PsF)” in F3 (VIDEO) in SYSTEM SET UP menu on
the HD-D5 VTR.
For details, refer to pages 9 and 10 of the “Operating Instructions Supplement” for the AJ-HD3700H, AJ-HD3700A,
and AJ-HD3700B.
Server/Color Corrector/Telecine
HD House Reference Signal
HD/SD Player/Recorder
HD analog Signal Router
HD-D5 VTRs
(AJ-HD3700H, AJ-HD3700A, AJ-HD3700B)
2K Processor (AJ-HDP2000)
HD SDI Signal Router
2048/1920 4:4:4
Dual-Link SDI Signals
2K SYSTEM connection
Existing SYSTEM connection
