35
5. ANGLE MEASUREMENT
5.1 Measuring an angle
Aim at the first target, then press [F3] [0 SET]
twice in succession to reset the
horizontal angle to 0.
Aim at the second target,
then read the horizontal angle.
Pressing [F4] [DISP] displays the vertical angle.
• The [0 SET] key cannot reset the vertical angle to 0.
• Pressing the [DISP] key cycles through the sets of display items:“H.angle/H.dst./V. dst.”,
“H angle/V.angle/S.dst.”, and “H.angle/V. angle/H.dst./S.dst./V.dst.”.
• Even though you turn the power off during a survey, the horizontal angle displayed
last time is saved, so that it is restored when the power is turned on next time.
• When the restored horizontal angle is not necessary, reset it to 0.
5.2 Resetting the horizontal angle to 0
Pressing [F3] [0 SET] twice in succession
resets the horizontal angle to 0° 0' 0".
• The [F3] [0 SET] cannot reset the vertical angle to 0.
• Pressing the [F3] [0 SET] accidentally during measurement does not reset the
horizontal angle to 0 unless you press it again. Once the buzzer stops sounding,
you can go to the next step.
• You can reset the horizontal angle to 0 any time except when it has been held.
H.angle
H.dst.
V.dst.
0° 00’ 00”
MEAS TARGET 0 SET DISP MODE
MODE A 15°C S 0
H.angle
H.dst.
V.dst.
60° 30’ 20”
MEAS TARGET 0 SET DISP MODE
MODE A 15°C S 0
H.angle
H.dst.
V.dst.
60° 30’ 20”
87° 05’ 40”
MEAS TARGET 0 SET DISP MODE
MODE A 15°C S 0
H.angle
H.dst.
V.dst.
0° 00’ 00”
MEAS TARGET 0 SET DISP MODE
MODE A 15°C S 0
