Applications
10
Mandatory Configuration
The P1705 & P1730 requires a minimum amount of mandatory configuration in order to
operate. The following table identifies the configuration parameters that must be defined
for proper operation under the operational states shown in the table.
Bridge IP Router IPX Router
none IP Address none
ISDN - U ISDN – S/T PPP ISDN
ISDN Switch Type ISDN Switch Type B channel assignment
Directory Numbers Directory Numbers Remote Site Profile
Frame Relay Lease Line PPP Lease Line
none (North America) none none (International)
Remote Site Profile
Frame Relay enabled
(International only)
Frame Relay disabled
(North America only)
The configuration options required for proper initial operation are described in Section 2:
Typical Applications and How to Configure Them. Each configuration requires a different
set of parameters to be entered.
Refer to Section 2 for details on configuring the P1705 & P1730 in different operational
states. Also refer to the P1705 & P1730 Menus Manual file for your operating software on
the accompanying CD-ROM for a complete description of all the Menu Options.
Other options may be changed depending upon specific installation configurations. Refer to
the menu tree in Appendix A for a reference of the menu structure and options.
