57
SDI outputs SD [SMPTE 59M standard complied with]
• Output return loss
More than 15 dB (5 MHz to 70 MHz)
• Output level 0.8 Vp-p 10 %
• Rise time Less than 1.5 ns
• Fall time Less than 1.5 ns
• Difference between rise time and fall time
Less than 0.5 ns
• Jitter Less than 0. UI
Analog HD input
(option) HD analog component Y/Pb/Pr (1.0 Vp-p, 75 )
IN1 to 5
Analog HD output HD analog component Y/Pb/Pr (1.0 Vp-p, 75 )
PGM, PVW, AUX
DVI-I input SXGA 180  104, XGA 104  768 (60 Hz)
Key input 1 input from video inputs
Reference input Black burst or Tri-level Sync (with loop-through)  1
Reference output In gen-lock mode: loop-through output  1,
In internal sync mode: black burst 
Video delay time Frame synchronizer OFF 1H
Frame synchronizer ON 1F
Control I/O Ethernet 100 Mbps/10 Mbps  1
Image transmission function available
(provided with transmission program)
Serial communication
interface RS-4A (D-SUB 9-pin)  1
Tally output Open collector outputs (negative logic) 1 to 6
GPI Auto take  1
Ambient operating
temperature
3 °F to 104 °F (0 °C to 40 °C)
Humidity 10 % to 90 % (no condensation)
Power supply DC 1 V  V
Power consumption 46.8 W
Dimensions
(W  H  D) 16-1/8"  4-1/16"  9-1/" (410  103.5  40 mm)
[Excluding protrusions]
Weight 7.1 lbs. (3. kg)
Standard accessories
Operating instructions ................................................................. 1
Operation manual / Image transmission program install CD ...... 1
Optional accessories
HD analog board AV-HSB300
Refer to the operating instructions that come with the HD analog board for details about the installation method.
Specifications and standard accessories
