2. Basic operations
2-7. Preset memory
Up to 10 panel settings can be stored in this memory.
The table below lists the settings which are stored.
Item
Description of setting
Initial value (factory default)
Crosspoint
A bus
1
B bus
1
KEY-S
1
KEY-F
1
AUX bus
1
Color background
WHITE
Wipe
Wipe pattern
4 (center)
Border width
0
Soft effect width
0
Border color
WHT
Transition area
BKGD/KEY selection
BKGD
MIX/WIPE selection
MIX
Auto transition time (BKGD)
30F
Auto transition time (KEY)
30F
Key
Key type (TYPE)
LIN
Key adjustment (ADJ)
GAIN: 100
CLIP: 0
DENS: 100
Invert ON/OFF
OFF
Fill color
BLE
Edge color
YLW
Edge ON/OFF (TYPE)
OFF
Edge width
User color
User color 1 (HUE, SAT, LUM)
0, 0, 100
User color (HUE, SAT, LUM)
355, 100, 7
User color 3 (HUE, SAT, LUM)
50, 100, 9
User color 4 (HUE, SAT, LUM)
0, 0, 0
The data stored in the preset memory will not be initialized even when initializing is performed.
STORE: This is used to store the panel settings in the preset memory.
1
Press the [FUNC] switch to light its indicator, and then press the [MEM] switch to display the MEM menu.
The PSMEM (1/3) menu appears first.
2
Turn [F], select “STOR” using the MODE item, turn [F3], and set the preset memory number using the NO.
item.
3
Press the [F4] switch (EXEC) to store the settings.
3&$-
$-3
14.&.
.0%&
4503
/0
&9&$
An asterisk ( ) appears at the left of the number when data has been saved in the preset memory.
