1
2. Basic operations
Adjusting the fill color
The fill color can be adjusted when USR1 to 4 have been selected. Use of USR1 to 4 is shared by the border
color, color background and edge color.
1 Press the [FUNC] switch to light its indicator, and then press the [KEY] switch to display the KEY menu.
2 Turn [F1] to display the USR1 to 4 (user color) menu.
3 Turn [F], [F3] and [F4] to adjust the color (HUE, SAT and LUM).
‰ ‰ ‰
643 )6& 4"5 -6.
2-3-5. Key decorations
Setting the key edge
A border, shadow or other edge can be added to the key.
1 Press the [FUNC] switch to light its indicator, and then press the [EDGE] switch to display the EDGE menu.
The EDGE menu (sub menu) appears first.
2 Turn [F] to select the edge type.
OFF: An edge is not added.
BODR (BORDER): A border is added around the entire edge.
DROP:
A diagonal border is added but only in the direction toward the bottom right of the key.
SHDW (SHADOW): A shadow is added but only in the direction toward the bottom right of the key.
OUTL (OUTLINE): An outline (only a border with no fill) is added.
3 Turn [F3] to set the edge width.
4 Turn [F4] to select the edge color.
"/2$%2
$2/0
3(!$/7
/54,).%
YLW
CYN
GRN
MGT
RED
BLE
BLK
USR1
USR2
USR3
USR4
0—4 BODR
DROP
SHDW
OUTL
EDGE
1/5
TYPE
OFF
WIDT
2
COLR
WHT
