Page 9
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
1
VYQ3933
OPTICAL U
1 FOR AJ-HPX2000P
1
VYQ3863
OPTICAL U
1 FOR AJ-HPX2100E/MC
2
VMA0T71
HEAT SINK (R)
1
3
VMA0T72
HEAT SINK (G)
1
4
VMA0T73
HEAT SINK B
1
5
VMA0V41
HEAT SINK BASE
1
6
VXQ1446
O.LPF U
1
7
VDW1228
LENS MOUNT RING
1
8
VDS0169
MOUNT CAP
1
9
VEE2804
EARTH CABLE
2
101
XQN2+C4FJ
SCREW
3
104
XYN3+C6FJ
SCREW
2
105
XYN26+F6FJ
SCREW
6
106
XQS2+A4FJK
SCREW
3
108
XSB3+6FJK
SCREW
4
E11
VEP20B25C
CCD P.C.BOARD
1
E15
VEP80D27A
POSITION SENSOR P.C.BOARD
1 FOR AJ-HPX2000P
E15
VEP80D28A
POSITION SENSOR P.C.BOARD
1 FOR AJ-HPX2100E/MC
CAMERA PARTS ASSEMBLY(2)
MPL-8
