LC1502R User’s Guide

(020-0315-02B)

Going to Sleep

This message means the LCD display is under the power saving mode. In addition, the LCD display

will go to this sleeping mode when experiencing a sudden signal disconnecting problem.

Unsupport Mode

This message means the signal of the computer graphic card is not compatible with the LCD display.

When the signal is not included in the compatibility mode we have listed in the Appendices of this

manual, the LCD display will appear this message.

Out of Range

This typically means the refresh rate or resolution is set too high. Set the resolution to 1024 x 768 and

set the refresh rate to 75 Hz or lower. On a PC, these adjustments are typically made using "Display

Properties" in the Control Panel folder.

Faint Horizontal Dark Lines Across the Screen

This display is directly backlit by cold cathode fluorescent lamps. Slight brightness nonuniformity is

normal.

Mechanical Outline

See mechanical outline drawing on www.planar.com/support
