20 LC1502R User’s Guide (020-0315-02B)
Specifications
Electrical and Optical
Parameter Min Typ Max Units Conditions/Notes
Input Power, Voltage 11.4 12.0 12.6 volts
Input Power, Current 3.95 4.3 amps
Monitor Power Consumption 47.4 49.2 watts
Logic High 4.0 5 5.4 volts For logic inputs
Logic Low -0.4 0 1.0 volts For logic inputs
DIM input voltage 0 5 volts Analog input
Maximum White Luminance 1,2 1050 1250 cd/m2 Center; Normal
Minimum White Luminance 1,3 350 cd/m2 Center; Normal
Dimming range 4 2:1 4:1 Ratio of max
lum/min lum
Luminance Uniformity 2 69 78 % 9-point; 10%
from edge
Contrast Ratio 1,2 600 White/black,
Center
Horizontal Viewing Angle ±80 deg Contrast ratio > 5
Vertical Viewing Angle +55/-54 deg Contrast ratio > 5
Response Time 16 23 msec rise time + fall time
Screen Diagonal, viewable 15 inches
Active Display Area 304.1 mm
x 228.1
Resolution 1024 pixels
x 768
Pixel Pitch 0.297 mm
Number of Supported Colors 262144
Note 1: 25°C steady state conditions at initial use
Note 2: No dimming
Note 3: With maximum dimming and factory set minimum brightness limit
Note 4: With factory set minimum brightness limit
