7
AC adapter
terminal
USB Port
Figure 3
Rear View
AC adapter terminal
• Connect the supplied AC adapter to the printer’s AC adapter
terminal (Refer to Figure 3) for connection to power source.
Printer’s USB port
• Connect the supplied USB cable to the USB port
(Refer to Figure 3) for connection to your PC.
PRINTING FUNCTIONS
The CD/DVD Printer provides printing in up to 4 sectional areas to
create a CD/DVD label.
• Top, right, bottom and left areas each covered at 90
0 intervals
• Easy-to-use selection of areas to edit.
Supports creation of Text and Graphics Labels
• Original text labels
• Curved text labels
• Resizable images
Text
Curved Text
Graphic
Print Area
