PLUS Vision DLPTM Technology Projector - Manual (Page 21)

User’s Manual
Operation 17
Setting effects
Resize When Resize is 4:3 or 16:9, the projector determines the best fit of the image to
the screen.
H. Phase If flicker occurs on a projected image, users may try to adjust the H. Phase
manually.
H. Size If the projected image is too wide or too narrow for the screen, users may turn
Auto Image off and adjust the H. Size manually to fit the screen size.
H.Position (move the image left) (move the image right)
The Auto Image should be turned off to activate the H. Position item. Position
adjustments are saved when the projector is power off.
V. Position (move the image down) (move the image up)
Position adjustments are saved when the projector is power off.
Image Ratio 4:3 (Normal) 16:9 (Wide)
System To select the input video system standard. When an AV box or turner box is
attached, the projector will automatically detect the video system.
Color (Less) (More)
Tint (Red) (Green) Source is Video or S-
Video.
*Tint may not be adjusted with PAL/SECAM video signal input.
C. Control Page
When users go into the Control sub-page, the first item “Auto” will be highlighted. There are five
items on this page: Reset, Language, Mirror, Auto Off and Reset (Fig. 26).
Figure 26 Control sub-page Figure 27 Language selection
