User’s Manual
Operation 15
Resetting Lamp Timer
If replacing the lamp after 1500 hours of operation, please carry out the following operation within 10
minutes of powering on.
OSD FUNCTION
Press the MENU button into OSD menu, and
use “
4” (KEYSTONE+) or “3”
(KEYSTONE-) to select the Control page.
Then press the Menu button again to highlight
the Lamp item.
Press “
4” (KEYSTONE+) or “3”
(KEYSTONE-) buttons, the lamp usage time will
display on the bottom of the screen and can be
adjusted.
•
Use the “
4” (KEYSTONE+) or “3”
(KEYSTONE-) buttons to select the "Reset"
item and press the “MENU” to reset the
usage time.
•
After reset the usage time, press “EXIT”
(AUTO) to save and exit.
OSD
Main OSD Menu
Press the “Menu” key and the main OSD menu
structure will display as shown at right hand (Fig.
21). Whenever AV box is attached, 4 sub-pages
will display in the menu: Display page, Image page,
Control page, and Source page. However if input is
from PC and no AV box is attached, Source page
will not display in the menu.
Press the “Menu” key again to enter Display page
items, or press “
3” (KEYSTONE-) or “4”
(KEYSTONE+) to select sub-pages. (The main
OSD menu will automatically disappear if a key is
not pressed within 10 seconds).
Press the “Exit” (AUTO) button to leave the
current sub-page, and press “Exit” (AUTO) button again to leave the main OSD menu (at the same
time the settings are saved).
Input status PC input without AV box PC input with AV box Video input with AV box
Subpage Display
Control
Display
Control
Source Display
Control
Source
Figure 21 Main OSD menu
