User’s Manual
Operation 11
The remote control allows you to operate the function keys on the projector and to emulate mouse
function when the projector is connected to a computer.
Inserting Batteries in the Remote Control
Be sure to follow instructions in placing batteries into the remote control units.
• Push and slide the lid in the direction of the arrow.
• Install two ’AAA’ batteries as indicated inside the battery compartment.
• Replace the lid and snap into place.
Caution
• Avoid excessive heat and humidity.
• Do not mix new and old or different types of batteries.
Figure 15 Battery replacement process
Main Unit Function
Standby/On To turn the projection lamp on and off.
Freeze Pressing this button displays a still (frozen) picture.
Magnify Pressing this button partially magnifies a displayed picture.
(Move the picture with the Disk Pad after pressing the Magnify button.)
Disk Pad When the OSD menu is active, Disk Pad acts as
56selecting device. When the on-
screen menus are not active, it works as mouse pad. When the magnify function is
active, use disk pad to move through the picture.
Menu Call the OSD Menu.
To enter sub pages.
To select items.
Blank The blank screen is displayed by pressing Blank. And the blank screen will be revealed
partially from top to bottom by pressing Blank again.
Source Selects the input source.
Mute Mutes the sound.
Volume Adjusts volume. The sound gets louder or quieter by pressing the "+" or "-" button.
Laser Laser pointer on button. Use as a stick (for indication).
Mouse Left-Click When operating in mouse emulation mode, it registers a left mouse click.
Mouse Right- Click When operating in mouse emulation mode, it registers a right mouse click.
Exit To leave current OSD Pages.
34Drag To move Left/Right among OSD items.
