SPECIFICATIONS
General
Power Supply: DC 12 V (11 V to 17 V)
Power Consumption: 36 W
Operating Humidity: 10 % to 85 %
Operating Temperature: 32°F to 104°F (0°C to +40°C)
Dimensions : 5-1/16" x 10-11/16" x 13"
(W x H x D) (129 x 271 x 329 mm)
Weight: About 9.9 bs (4.5 kg)
About 16.7 lbs (7.6 kg) in full-operation
Continuous Rec Time: About 120 min. with Anton/Bauer Dionic 90
Camera Section
CCD Elements: 2/3” HD Progressive CCD
Picture Elements: Total: 1370 (H) x 744 (V), Effective: 1280 (H) x 720(V)
Optical System: F 1.4 prism system
Optical Filters: CC: Cross, 3200K, 4300K, 6300K
ND: CLEAR, 1/4ND, 1/16ND, 1/64ND
Quantization: 14 bits
Sampling Frequency: 74.1758MHz (59.94Hz), 74.25MHz (50Hz)
Programmable Gain: –3/0/+3/+6/+9/+12/+15/+18/+21/+24/+27/+30 dB
Super Gain: +30/+36 dB
Digital Super Gain: +6/+10/+12/+15/+20 dB
Line Mix Gain: +6 dB (On/Off)
Shutter Speed: 1/60 (50Hz), 1/100 (59.94Hz), 1/120, 1/250, 1/500,
1/1000, 1/2000 sec. and HALF
Syncro Scan Shutter: 1/60.3 to 1/249.8 sec. (59.94i, 59.94p)
1/30.2 to 1/249.8 sec. (29.97p)
1/24.1 to 1/249.8 sec. (23.98p, 23.98pA)
1/50.2 to 1/209.5 sec. (50i, 50p)
1/25.2 to 1/209.5 sec. (25p)
Sensitivity: F10 at 2000 lx, 89.9% reflect
Minimum Illumination: 0.032 lx at +36 dB +20 dB +6 dB Gain
Video S/N: 54 dB (typical)
Horizontal Resolution: 700 TV lines at centre
Registration Error: Less than 0.03 % (whole zone, without lens distortion)
Lens Mount: 2/3" Bayonet type
VTR Section
Recording Fromat: DVCPRO HD-LP
Tape: 6.35 mm wide metal tape (DVCPRO HD M cassette)
Tape Speed: 67.640 mm/s (59.94Hz), 67.708 mm/s (50Hz)
Max Rec Time: Approx. 33 min (using AJ-HP33EMG)
FF/REW Time: About 1.5 min. (using AJ-HP33EMG)
Video
Sampling Frequency: Y: 74.1758 MHz (59.94Hz), 74.25MHz (50Hz)
PB/PR: 37.0879 MHz (59.94Hz), 37.125 MHz (50Hz)
Quantization: 8 bits
Compression Method: DCT and Variable-length Coding
Compression Ratio: 1/6.3 (1080-50i/1080-25p), 1/6.7 (others)
Error Correction: Reed Solomon Product Code
Bit Rate: 100 Mbps
Band Width: Y: 20MHz, PB/PR: 10MHz
Audio
Sampling Frequency: 48 kHz (sync. with video)
Quantization: 16 bits
Frequency Response: 20 Hz to 20 kHz, ±1.0 dB (reference level)
Dynamic Range: More than 85 dB (1kHz, AWTD)
Distortion: Within 0.1% (1 kHz, reference level)
Wow & Flutter: Below measurable limit
Head Room: 20 dB (AJ-HDX900P), 18 dB (AJ-HDX900E)
Input
MIC In: XLR-5pin x 1, Stereo, –40/–50 dBu, Phantom +48 V
Audio In: XLR-3pin x 2 (CH1/CH2),
LINE/MIC/MIC+48 V switchable
LINE: –3/0/+4 dBu, MIC: –60/–50 dBu,
MIC+48V: –60/–50 dBu,
Wireless In: 25pin D-sub, –40 dBu
Genlock In: BNC x 1, 1.0 Vp-p, 75 Ω
Timecode In: BNC x 1, 0.5 to 7.0 Vp-p, high impedance
Output
Video Out: BNC x 1, HD-SDI/SD-SDI/Compsite switchable
HD-SDI/SD-SDI: 0.8 Vp-p, 75
Ω
Composite: 1.0 Vp-p, 75 Ω
Monitor Out: BNC x 1, HD-SDI/HD-Y switchable
HD-SDI: 0.8Vp-p, 75
Ω , HD-Y: 1.0Vp-p, 75 Ω
Audio Out: XLR-5pin x 1, CH1/CH2, –3/0/+4 dBu
Timecode Out: BNC x 1, 2.0 Vp-p, low impedance
Phones: Stereo mini jack x 2
Others
Lens: 12-pin x 1
Remote: 10-pin x 1, for AJ-RC10G
DC In: XLR-4pin, DC11V to 17 V
DC Out: 4-pin x 1, DC11V to 17 V, max. 1.5 A
EVF: 20-pin x 1 (59.94Hz/50Hz switchable)
DVCPRO: 6-pin x 1, IEEE 1394 standard digital Interface
GPS: 6-pin x 1, for AJ-GPS900G
Receiver : UniSlot® Wireless Receiver
*DVCPRO HD-LP tapes recorded with the AJ-HDX900 cannot be played on a conventional DVCPRO
HD VTR (AJ-HD150/AJ-HD130DC).
*UniSlot® is a trademark of Ikegami Tsusinki Co., Ltd.
