Frame & casing parts assembly(2), Mpl-4 – Panasonic AG-HVX202AEN User Manual
Page 5
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
71
VMG1727
LENS CUSHION
1
1
VGM2154
TOP PANEL U
1
72
VGU9219
CAMERA/VCR BUTTON
1
2
VKM6880
MAIN FRAME
1
73
VSC5833
CERAMIC SEAT HEAT RADIATION 4
3
VYK1U94
ZOOM SW CASE U
1
74
VSC5824
CDS HEAT SINK
1
4
VGM2280
JACK FRAME
1
75
VMZ3465
CD CON CUSHION
1
5
VKW3303
AWB SENSOR WINDOW
1
76
VSC5845
CDS RADIATION SHEET
1
6
VGQ8838
AUDIO SW COVER
1
78
VYF3081
EVR COVER U
1
7
VGU0A01
MODE SW KNOB
4
79
VMT1766
EVF FPC CUSHION
1
8
VMT1761
FRONT MIC SW SHEET
2
80
VMZ3631
C.B.A. BARRIER
1
9
VMP8589
AUDIO SW PLATE
1
81
VGF1050
DUSTPROOF SHEET
1
10
VWJ12H2040L0 12PIN40MM FFC
1
82
VGU9925
REC CHECK BUTTON
1
11
VYK1Y37
BACK PANEL 1U
1
83
VGU9215
ZOOM LEVER
1
12
VYK2J42
SIDE CASE R 1U
1
84
VMZ3406
ZOOM PCB BLIND SHEET
1
12-1
VMG1286
CUSHION RUBBER
2
85
VWJ1844
SIDE JACK FPC
1
12-2
VMZ3757
FPC PROTECTION SHEET A
1
86
VMT1749
FFC FIX SHEET
2
12-3
VYQ3806
IR SENSOR WINDOW
1
87
VEE1C05
BATTERY-POWER CABLE
1
13
VYK1U47
LCD U
1
88
VWJ06H2060L0 6PIN FFC
1
14
VGQ8773
LCD HINGE COVER
1
89
VJF1468
XLR CAP
2
15
VWJ06H2033L0 6PIN33MM FFC
1
90
VMT1774
CORE TAPE
1
16
VEK0J73
IRIS DIAL U
1
91
J0KD00000103 CORE
1
17
VGU9929
AWB BUTTON
1
92
VGU0D09
TOP OPERATION BUTTON
1
18
VSC5806
SIDE R HEAT SINK
1
93
VGU9195
VTR KNOB
1
19
VMP8615
TRIPOD FRAME
1
94
VGU9210
REC/DUB BUTTON
1
20
VYQ3733
CLUTCH U
1
95
VMZ3768
RCA INSULATING SHEET
1
20-1
VGU9936
CLUTCH KNOB
1
96
VSC6051
USB GROUND ANGLE
1
20-2
VGP6167
CLUTCH PANEL
1
97
VYQ3897
RCA PLATE U
1
20-3
VMP8557
CLUTCH FRAME
1
98
VMT1907
SOFT HIGH SHIELD GASKET
1
21
VMP8558
CLUTCH ARM ANGLE
1
99
VMT1896
FPC HOLD CUSHION
1
22
VYK1Y38
BATTERY CASE 1U
1
23
VSC5801
CCD HEAT SINK
1
24
VWJ10H2030L0 10PIN30MM FFC
1
25
VWJ12H2050L0 12PIN50MM FFC
1
201
XQN2+B4FN
SCREW
76
26
VWJ06H2045L0 6PIN45MM FFC
1
202
XQN2+BJ5FJK
SCREW
5
27
VGU9894
SLIDE KNOB
4
203
XYN26+A6FJK
SCREW
2
28
VGH4857
SLIDE KNOB SHEET
4
204
XQN2+BJ6FJ
SCREW
2
29
VGU9931
LCD BUTTON B
1
205
XQN2+B4FJK
SCREW
27
30
VGU9935
COUNTER BUTTON
1
206
XYN2+C5FJ
SCREW
2
31
VGU9930
LCD BUTTON A
1
207
XQN2+BJ4FJK
SCREW
2
32
VGU9937
EVF DTL BUTTON
1
208
XQN16+BJ4FJK SCREW
4
33
VGU9197
MONITOR LOCK KNOB
1
209
XQN2+A5FJK
SCREW
1
34
VMB4017
FOCUS SPRING
1
210
VHD1887
SCREW
7
35
VGQ8772
CAM OP BACKUP
1
36
VGU9928
ND KNOB
1
37
VGU9926
FOCUS KNOB
1
38
VGU9927
CAM OP BUTTON
1
E1
VEP03G90C
VTR C.B.A.
1 FOR AG-HVX200AP/AAN
39
VMP7331
OPENER HOLDER ANGLE
1
E1
VEP03G90D
VTR C.B.A.
1
FOR AG-HVX201AE/AEN/AMC/AER
40
VMB3996
POP UP SPRING
1
E2
VEP23655D
CAMERA C.B.A.
1 FOR AG-HVX200AP/AAN
41
VGQ6901
MONITOR KNOB
1
E2
VEP23655E
CAMERA C.B.A.
1
FOR AG-HVX201AE/AEN/AMC/AER
42
VMS7187
LCD LOCK SHAFT
1
E3
VEP03G89F
CODEC C.B.A.
1 FOR AG-HVX200AP/AAN
43
VMB3659
MONITOR OPENER SPRING
1
E3
VEP03G89G
CODEC C.B.A.
1
FOR AG-HVX201AE/AEN/AMC/AER
44
VWJ06H2033L0 6PIN33MM FFC
1
E4
VEP001M6A
R SIDE C.B.A.
1
45
VMP8552
JACK ANGLE
1
E5
VEP06G20A
CAM OP1 C.B.A.
1
46
VWJ12H2120L0 12PIN120MM FFC
1
E6
VEP06G21A
CAM OP2 C.B.A.
1
47
VWJ16H2145L0 16PIN145MM FFC
1
E7
VEP06G22A
CAM OP3 C.B.A.
1
48
VGH4874
JACK PLATE
1
E8
VEP01978A
POWER C.B.A.
1
49
VGU9721
AUDIO VR KNOB
2
E9
VEP03G92C
P2 CARD C.B.A.
1
50
VYQ3547
MODE DIAL U
1
E11
VEP04904A
SIDE JACK2 C.B.A.
1
51
VEE1C06
AUDIO CABLE
1
E12
VEP001P2A
SD CARD C.B.A.
1
52
VWJ24H2030L0 24PIN30MM FFC
1
E14
VEP001M1C
TOP OP C.B.A.
1
53
VEE1C12
1394 CABLE
1
E15
VEP001M2B
BACK PANEL C.B.A.
1
54
K4ZZ04000036 BATTERY TERMINAL
1
E16
VEP04902C
SIDE JACK 1 C.B.A.
1
55
VEE1C20
DC IN-BATTERY CABLE
1
E17
VEP04903B
EXT MIC 2 C.B.A.
1
56
VMP7340
DCIN ANGLE
1
E21
VEP001M4A
POWER SW C.B.A.
1
57
VYK1U97
SIDE COVER LU
1
E22
VEP01979A
BATTERY C.B.A.
1
58
VGQ9900
LINE SHEET
2
E23
VEP01971A
DC IN P.C.BOARD
1
59
VJF1544
SD CARD CAP
1
E24
VEP001M5B
ZOOM SW C.B.A.
1
60
VJF1545
USB COVER
1
E26
VEP22370A
GYRO C.B.A.
1
61
VJF1541
JACK COVER
1
E27
VEP03G96A
CAMERA TOP FPC C.B.A.
1
62
VSC5805
SHIELD PLATE B
1
E28
VEP03G94A
CODEC P2 FPC C.B.A.
2
63
VSC5804
SHIELD PLATE A
1
E29
VEP001N2A
TOP CON C.B.A.
1
64
VWJ1845
CAMERA TO SIDE CASE-R FPC
1
65
VYQ3807
ZOOM SW 1 U
1
66
VJF1543
SIDE JACK CAP B
1
67
VJF1542
SIDE JACK CAP A
1
68
VGH4876
JACK NAME PLATE 2
1
69
VMZ3758
HINGE FPC HOLD SHEET
1
70
VSC5850
P2 CARD SHELD PLATE
1
FRAME & CASING PARTS ASSEMBLY(2)
MPL-4
