Connections, 14 en, Connection to the tv – Philips BDP7200 User Manual
Page 14
14
EN
COMPONENT
VIDEO OUT
P
B
/C
B
P
R
/C
R
Y
COMPONENT
VIDEO IN
Y
P
B
/C
B
P
R
/C
R
AUDIO IN
L
R
5.1ch AUDIO OUT
AUDIO
OUT
FL
SL
C
L
R
FR
SR
SW
DIGITAL OUT
(PCM/BITSTREAM)
COAXIAL
OPTICAL
DIGITAL OUT
(PCM/BITSTREAM)
COAXIAL
OPTICAL
AUDIO
OUT
L
R
CONNECTIONS
VIDEO
OUT
VIDEO
IN
HDMI OUT
HDMI IN
HDMI OUT
DVI IN
*
1)
This unit is compatible with the progressive scan system. The feature provides you with the higher quality pictures than traditional
output system does. To utilize this feature, a component or an HDMI connection is required. Refer to the “HDMI Video Resolution”
on page 31 or “Component Output” on page 31 to set the resolution.
*
2)
Analog audio connection is not required for this connection.
Supplied cables used in this connection are as follows:
RCA audio cable (L/R) x 1
RCA video cable x 1
Please purchase the rest of the necessary cables at your local store.
•
•
Note for HDMI connection (Philips recommends HDMI category 2 cable, also known as High
Speed HDMI cable, for optimal audio / video output.)
A simple 1-cable connection with a device having an HDMI (High-Definition Multimedia Interface) jack allows
digital transfer of the digital pictures of BD-video, DVD-video and other devices.
•
Make one of the following connections, depending on the capabilities of your existing device.
•
TV
this unit
and
HDMI
cable
analog audio
RCA
audio cable
RCA
video
cable
component
video cable
Method 2
better picture
COMPONENT
VIDEO OUT
Method 1
standard picture
VIDEO OUT
AUDIO OUT
Method 3
best audio/picture
HDMI OUT
HDMI-DVI
cable
*
1
*
1
AUDIO CONNECTION
VIDEO CONNECTION
AUDIO/VIDEO
CONNECTION
or
best picture
Method 4
*
1, 2
or
or
(Red)
(Blue)
(Green)
(Red)
(Blue)
(Green)
Connection to the TV
