Many of the Device Server’s configuration procedures require you to assemble a
series of options (represented as bits) into a complete command (represented as a
byte). The resulting binary value must be converted to a hexadecimal representation.
Hexadecimal digits have values ranging from 0 to F, which are represented as 0-9, A
(for 10), B (for 11), etc. To convert a binary value (for example, 0010 0011) to a
hexadecimal representation, the upper and lower four bits are treated separately,
resulting in a two-digit hexadecimal number (in this case, 4C).
Use the following table to convert values from binary to hexadecimal.
Binary to Hexadecimal Conversion Table
Decimal
Binary
Hex
0 0000
0
1 0001
1
2 0010
2
3 0011
3
4 0100
4
5 0101
5
6 0110
6
7 0111
7
8 1000
8
9 1001
9
10 1010
A
11 1011
B
12 1100
C
13 1101
D
14 1110
E
15 1111
F
In
4:Using Setup Mode
, the binary bit fields for options in connect mode, disconnect
mode, flush mode, interface mode, and pack control mode are described in detail.
The following pages are a summary of the possible hexadecimal entries for each of
these options.
