Monitoring the Network
Monitor Mode Commands
The following commands are available in Monitor Mode. Many commands have an IP
address as an optional parameter (xxx.xxx.xxx.xxx). If you enter the IP address, the
command is applied to another unit with that IP address. If you do not enter the IP
address, the command is executed locally.
Note: All commands must be in capital letters.
Table 7-1. Monitor Mode Commands
Command Command Name Function
VS x.x.x.x Version Queries software header record (16 bytes) of unit
with IP address x.x.x.x.
GC x.x.x.x Get Configuration Gets configuration of unit with IP address x.x.x.x as
hex records (120 bytes).
SC x.x.x.x Send Configuration Sets configuration of unit with IP address x.x.x.x
from hex records.
PI x.x.x.x Ping Pings unit with IP address x.x.x.x to check device
status.
AT ARP Table Shows the unit’s ARP table entries.
TT TCP Connection
Table Shows all incoming and outgoing TCP connections.
NC Network Connection Shows the unit’s IP configuration.
RS Reset Resets the unit’s power.
QU Quit Exits diagnostics mode.
G0, G1, ....,Ge, Gf Get configuration
from memory page Gets a memory page of configuration information
from the device.
S0, S1,...,Se, Sf Set configuration to
memory page Sets a memory page of configuration information
on the device.
Responses to some of the commands are given in Intel Hex format.
Note: Entering any of the commands listed above generates one of the
following command response codes:
Table 7-4. Command Response Codes
Response Meaning
0> OK; no error
1> No answer from remote device
2> Cannot reach remote device or no answer
8> Wrong parameter(s)
9> Invalid command
7-2 XPort™ User Guide
