16
Chapter 5: Bi-Admin:
PrintServer Management
The Wireless PrintServer is managed by a utility program called Bi-Admin on
the Wireless PrintServer’s Setup CD. Fully compatible with Windows 95, 98,
Millennium, NT, 2000, and XP, Bi-Admin allows you to change the Wireless
PrintServer’s internal settings, check on the unit’s status, and perform basic
diagnostic tests. Note that the Bi-Admin program must only be installed on the
network administrator’s computer.
1. To start the Bi-Admin program, click on Start, Programs, Linksys
PrintServer Admin, and then Bi-Admin. If the Bi-Admin icon has been
created, you can just double-click on it instead. You can drag the shortcut
icon onto your Desktop for easy access to the Bi-Admin program.
2. When the Bi-Admin program appears, it will ask for the Connected
Protocol. Make sure the box next to TCP/IP is checked. Click the OK but-
ton. Then the Bi-Admin program will automatically scan the network for
available Wireless PrintServer hardware. Any hardware found on the net-
work will appear in the Default Name, Device Name, and Printer Port cat-
egories on the right-hand side of window. Default Name is the SC number
located on the back or bottom of the Wireless PrintServer unit, and cannot
be changed.
Starting the Bi-Admin Management Utility
Wireless PrintServer
Overview
15
12. After your printer(s) have been added, you will return to the Configure
Printer Port screen. Click the Connect button to connect the printer(s).
13. The Printer Port Setup screen will appear again, displaying the printers
which are now communicating with the Wireless PrintServer. Click the
Next button to add any more printers or Close to complete the installation
and configuration procedure.
Instant Wireless™ Series
Figure 4-15
Figure 4-14
